项目/Item
|
单位
|
规格/Size
|
|
Unit
|
EH15
|
EH20
|
EH25
|
|
额定起重量/Capacity Q
|
KG
|
1500
|
2000
|
2500
|
|
载荷中心/Load centre C
|
MM
|
600
|
|
操纵方式/Manipulation
|
|
步行式/站驾式/Tramp type/standing steer type
|
|
最大起升高度/Max lift height H
|
MM
|
205
|
|
下降后货叉距地高度/Lower height h
|
MM
|
85
|
|
转弯半径/Turning tadius R
|
MM
|
1545
|
1545
|
1545
|
|
车身总长(不含踏板)Overall length(wo platform) L
|
MM
|
1770
|
1770
|
1770
|
|
车身总宽/Overall width B
|
MM
|
750
|
750
|
750
|
|
标准货叉尺寸(长/宽/高)/Standard fork(L/W/H)
|
MM
|
1150×160×50
|
|
货叉外宽/Fork overall size B1
|
MM
|
520/680
|
|
货叉内宽/Fork inside size B2
|
MM
|
200/360
|
|
行驶速度(满载/空载)/Traveling speed(with/withoutload)
|
KM/H
|
4.5/6
|
|
提升速度(满载/空载)/Lifting speed(with/withoutload)
|
MM/S
|
45/50
|
|
下降速度(满载/空载)/Lowering speed(with/withoutload)
|
MM/S
|
45/40
|
|
爬坡度（满载/空载）/Gradient(with/withoutload)
|
%
|
5/8
|
|
制动方式/Type of driver
|
|
电磁制动/Electromagnetic braking
|
|
驱动轮/Driving wheel
|
MM
|
φ250×80
|
|
驱动轮型式/Type of driver
|
|
卧式/Horizontal
|
|
承载轮/Load wheel
|
MM
|
φ80×70
|
φ80×70
|
φ80×70
|
|
平衡轮/Balance wheel
|
MM
|
φ125×50
|
φ125×50
|
φ125×50
|
|
驱动电机/Driving motor
|
KW
|
1.2
|
1.2
|
1.2
|
|
提升电机/Lifting motor
|
KW
|
1.1
|
1.1
|
1.1
|
|
蓄电池(电压/容量)Battery(Voltage/capacity)
|
V/AH
|
24V/160AH/210AH
|
|
控制类型/Controling type
|
|
Curtis 1207串励控制
|
|
自重(含电池)/Weight(with battery)
|
KG
|
390
|
430/450
|
450/470
|
